syncotek uhf fixed rfid reader for laundry SR-RU401

FOB Reference Price:Get Latest Price
$715.00 - $789.00 / Pieces | 1 Piece/Pieces (Min. Order)
Model Number:
SR-RU401
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SYNCOTEK
Product Name:
syncotek uhf fixed rfid reader for laundry SR-RU401
Protocol Tag:
ISO18000-6C (EPC C1G2)
RFID Engine:
Impinj R2000
Frequency Band:
840~868MHz/902~928MHz
RF Output Power:
up to 30dbm
Interface:
RS232, RS485, RJ45 (TCPIP)
Supply Ability
Supply Ability:
5000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
1PC/BOX 2.37KG
Port
Shenzhen

syncotek uhf fixed rfid reader for laundry SR-RU401



General Description:

SR-RU401 is a high performance UHF RFID fixed reader. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system.



Features:

*Designed with Impinj R2000 RFID engine

* Embedded Linux OS and running client’s application on the device

*Support ISO18000-6C (EPC C1G2) protocol tag

*840~868MHz/902~928MHz frequency band (frequency customization optional)

*FHSS or Fix Frequency transmission

*RF output power up to 30dbm (adjustable)

*4 TNC antenna port with antenna auto-tuning and failure-detection

*Support command, polling and trigger mode

*Tag buffer size up to 800PCS (Max. 496bits EPC length)

*Support EPC, TID and USER inventory

*Support RS232, RS485, RJ45 (TCPIP)

*Support wireless 3G/4G/WIFI/Bluetooth

* Support IAP firmware upgrading

*Support IE configuration



Characteristics:

*Absolute Maximum Rating

ITEM

SYMBOL

VALUE

UNIT

Power Supply

VCC

16

V

Operating Temp.

TOPR

-40~+80

Storage Temp.

TSTR

-40~+80



*Electrical and Mechanical Specification

Under TA=25℃,VCC=+12V unless specified

ITEM

SYMBOL

MIN

TYP

MAX

UNIT

Power Supply

VCC

9

12

16

V

Current Dissipation

IC



800

1200

mA

Frequency

FREQ

840



960

MHz

Size

Size



270×140×40



mm
